福祿克DTX-1800的永久鏈路DTX-PLA001到DTX-PLA002的轉變

福祿克DTX系列的儀器，如DTX-1800或者DTX-1200都有兩條Category 6A/Class EA永久鏈路DTX-PLA002S適配器。過去福祿克DTX-1800永久鏈路適配器DTX-PLA001永久鏈路使用的是DSP-PM06。從福祿克DTX-PLA001到DTX-PLA002的轉變是因為要實現6A類的外表串擾測試。

對于福祿克DTX-PLA001的用戶接頭為DSP-PM06接頭，連訊達推薦您使用DTX-PLA002。福祿克DTX-PLA002的芯片是可以更換的，當他磨損的時候。使用DTX-1800，DTX-1200，DTX-LT等DTX系列儀器的DTX-PLA002永久鏈路的拔插次數達到10000次，盡管官方公布的是“典型”>5000次拔插。

當您使用110規格的IDC接插插座的時候，您還是仍需要DTX-PLA001。

福祿克DTX-PLA001 與DTX-PLA001002永久鏈路

英文原文：The DTX CableAnalyzer currently ships with two DTX-PLA002 Category 6A/Class EA?Permanent Link Adapters. It used to ship with the DTX-PLA001 Permanent Link Adapter and DSP-PM06.?The change to DTX-PLA002 was required to support Category 6A/Class EA?testing and Alien Crosstalk testing.

Users of DTX-PLA001 with DSP-PM06 are encouraged to migrate to DTX-PLA002. It may not be obvious, but you can still?replace the tip on the DTX-PLA002when it wears out. Reports from the field suggest that the DTX-PLA002?will last well beyond 10,000 insertions, although the official specification for the tip of the DTX-PLA002 is “typically > 5,000 Insertions”.

You will however still need the?DTX-PLA001 if you are testing 110 Style IDC Wiring Blocks.
